Hardware Specifications
A practical specification overview for procurement, integration, marine installation, vehicle mounting, and fleet planning.
Early Access: Some specifications marked "TBD" are finalising as V1.0 moves through production.
Display
7"
Capacitive Touch
GNSS
Precision
GPS+GLONASS+Galileo
Accuracy
Sub-metre
Open sky CEP
Storage
128 GB
On-device maps
Power
5V
Vehicle or marine
Display
Size
7" diagonal
Touch
Capacitive multi-touch
Interface
DSI
Refresh Rate
Up to 60Hz
Positioning
GNSS module
u-blox NEO-M8N
Channels
72-channel receiver
Accuracy
2.5m CEP (open sky)
Without network augmentation
Update rate
Up to 18Hz
Cold start
~30 seconds
Warm start
1 second
Sensitivity
-161 dBm tracking
Operating temp
-45°C to +105°C
Power & Connectivity
Input voltage
5V Continuous
Input current
3A minimum
Connector
USB-C
Vehicle power
12V / 24V via buck converter
Step-down regulator required for vehicle install
Navigation Software
Map format
OpenStreetMap-derived vector tiles (MVT)
Routing engine
OSRM-based on-device routing
Routing profiles
Car, Truck (additional profiles TBD)
Elevation data
30m SRTM global dataset
POI database
Global OSM points of interest
Procurement Notes
Different deployments need different configurations. The items below affect what you order - talk to us before finalising a procurement decision.
The device ships pre-loaded with the vector map bundle for your region. Extended coverage (additional continents, remote territories) is available as an add-on.
ENC/S-57 nautical chart data is available as a separate add-on. Required for chart plotter and tidal prediction features in marine deployments.
Dashboard, helm, and flush-mount options have different brackets and cable routing requirements. OEM and fleet deployments can specify custom mounting at order.
The GPS Navigator operates fully offline without any API subscription. The Farun online APIs are separate developer products for building software with Farun spatial data.
Single units include a 1-year hardware warranty. Fleet pack and enterprise contracts can include extended 2-year warranty and dedicated onboarding support.
Items marked TBD are finalising as V1.0 moves through production. Discuss a specific procurement requirement by contacting us directly.
